4BTAA3.9 Diesel Engine for Generator Sets, Construction & Agricultural Machinery
The 4BTAA3.9 is an industrial diesel engine specially designed for non-road and stationary equipment.
Optimized for low-speed high torque and continuous operation, it is widely used in generator sets, construction machinery, agricultural equipment, and pump units.
4BTAA3.9 Engine Models
| Model | Rated Power (kW@rpm) | Max Torque (N·m@rpm) |
|---|---|---|
| 4BTAA3.9-C80 | 60 @ 2200 | 385 @ 1300 |
| 4BTAA3.9-C100 | 74 @ 2200 | 400 @ 1500 |
| 4BTAA3.9-C125 | 93 @ 2200 | 530 @ 1400 |
| 4BTAA3.9-C130 | 97 @ 2500 | 519 @ 1400 |
The 4BTAA3.9 diesel engine is a heavy-duty industrial power solution designed for stationary and non-road mobile applications.
Unlike automotive engines, the 4BTAA3.9 is calibrated to deliver strong low-speed torque, excellent load response, and stable continuous power output, making it ideal for equipment that operates under constant or heavy-load conditions such as generator sets, agricultural machinery, and construction equipment.
This engine is recognized worldwide for its durability, reliability, and low operating cost.
Performance Characteristics
-
Optimized Torque Curve
Designed to deliver high torque at low RPM, ensuring excellent pulling power for heavy-duty machinery. -
Continuous Duty Operation
Capable of long-term stable operation at rated speed, especially suitable for diesel generator sets and pump systems. -
Industrial Power Calibration
Power ratings are based on kW or continuous horsepower, different from automotive engine tuning.
Configuration & Design Features
-
Fuel System for Constant-Speed Operation
Equipped with a governor suitable for steady working conditions. -
Enhanced Cooling System
Radiator and water pump optimized for high-temperature and dusty environments. -
Flexible Flywheel & Housing Options
Compatible with clutches, gearboxes, and couplings for generators and industrial machinery. -
Adapted Exhaust Manifold Design
Exhaust orientation can be configured to meet different installation requirements.
Emission Compliance
Depending on the production year and configuration, the engine can comply with non-road emission standards, such as China Stage II / Stage III.
Applications
-
Power Generation
Diesel generator sets -
Construction Machinery
Loaders, air compressors, concrete equipment -
Agricultural Machinery
Tractors, combine harvesters, large agricultural equipment -
Pump Systems
Water pump units, irrigation systems -
Other Industrial Equipment
Stationary or off-road power applications
Technical Specifications
4BTAA3.9 Engine Models
| Model | Rated Power (kW@rpm) | Max Torque (N·m@rpm) |
|---|---|---|
| 4BTAA3.9-C80 | 60 @ 2200 | 385 @ 1300 |
| 4BTAA3.9-C100 | 74 @ 2200 | 400 @ 1500 |
| 4BTAA3.9-C125 | 93 @ 2200 | 530 @ 1400 |
| 4BTAA3.9-C130 | 97 @ 2500 | 519 @ 1400 |
General Specifications
-
Engine Type: Inline 4-cylinder, 4-stroke
-
Aspiration: Turbocharged & Aftercooled
-
Cooling System: Water-cooled
-
Fuel System: Mechanical Governor / Industrial Fuel System
-
Displacement: 3.9 L
-
Duty Type: Continuous / Heavy-duty
-
Application: Generator, Construction, Agriculture, Pump Systems
OEM configurations, different power ratings, and complete power solutions are available.
Contact us now for price, lead time, and technical support.
| Model |
4BTAA3.9 – C100 ,4BTAA3.9 – C125 ,4BTAA3.9 – C130 ,4BTAA3.9-C80 |
|---|---|
| Rated Power (kW@rpm) |
60@2200 ,74@2200 ,93@2200 ,97@2500 |
| Max Torque (N·m@rpm) |
385@1300 ,400@1500 ,519@1400 ,530@1400 |
| Series |
B Series |
